SBRINYOR GENTLE MIRROR è lo
specchio antiappannante di
Hourglass Italy Hgi, realizzato in
stretta ed esclusiva collaborazione
con una vetreria italiana
specializzata a completamento
della serie di specchi speciali.
La principale caratteristica dello
SBRINYOR GENTLE MIRROR è la
possibilità di rendere in pochi
minuti la superficie dello specchio
completamente pulita e libera dal
vapore di condensa, soprattutto
nella zona che viene ritenuta
interessante dall’utente, di solito
centrata rispetto all’altezza del viso
riflesso.
Il consumo energetico è molto
basso.

SBRINYOR GENTLE MIRROR is the
demisting mirror of Hourglass Italy
designed and made in close
cooperation with an Italian glass
company on completion of the
special mirrors range.
The principal characteristic of
SBRINYOR GENTLE MIRROR is the
possibility to get in a few minutes
the mirror surface clean and free of
the vapor moisture, above all in the
area interesting to the user usually
focused on the mirrored face of
the person.
The power consumption is very low.

ZONE RISCALDATE
HEATED ZONES

Svariate sono le combinazioni
di riscaldamento a zone, dalle
forme rettangolari fino al
cerchio e all’ellisse.
Se richiesto a zone multiple o
sull’intera superficie dello
specchio, anche sagomato.

There are several chances of
the zone heating, from the
rectangular to the circle and
ellipse ones.
Upon request multiple zones or
on the whole surface of the
mirror even shaped.

COMPOSIZIONE SPECCHI SPECIALI
SPECIAL MIRRORS COMPOSITION

Hourglass Italy Hgi propone degli specchi stratificati che possono essere
costruiti nelle composizioni più complesse in base alle esigenze stilistiche e
creative dei designers e alle necessità tecniche di produzione.

RETE ARGENTATA

RETE ARGENTATA

SILVER FABRIC MESH

RETE DORATA

SILVER FABRIC MESH

GOLDEN FABRIC MESH

Hourglass Italy Hgi offers laminated mirrors that can be made with
elaborate shapes and compositions according to the creative stylistic needs
of the designers and of the technical production.

SPECCHIO CON TESSUTO NON TESSUTO

SPECCHIO DORATO CON RETE

MIRROR WITH NON WOVEN FABRIC

GOLDEN MIRROR WITH MESH

SPECCHIO ACCOSTATO A MATERIALI SPECIALI
MIRROR MATCHED TO SPECIAL MATERIALS

Hourglass Italy Hgi propone
degli accostamenti speciali
degli specchi con materiali
particolari.

Hourglass Italy Hgi has
designed special matching
of the mirrors to particular
materials.

DATI SPECCHIO RISCALDANTE
SPESSORE VETRO
SPESSORE VETRO
SPESSORE VETRO
SPESSORE VETRO

mm 3
mm 4
mm 5
mm 6

PESO
PESO
PESO
PESO

7,5 Kg / mq
10,0 Kg / mq
12,5 Kg / mq
15,0 Kg / mq

ZONA RADIANTE MAX

mm 1200 x 2000 mm

TEMPERATURA MAX

15°C

VOLTAGGIO

12V, 24V, 110V, 240V - 50 Hz, 60Hz

WATTAGGIO

200 Watt / mq

SCATOLA CONNESSIONE

mm 30 x 30 x 5

CONNESSIONE ELETTRICA diretta o in parallelo, cavo da 80 cm
VETRO SPECCHIO BASE

float chiaro o extrachiaro

SICUREZZA

Stratificazione o pellicola posteriore

DECORAZIONE

rete, tessuto, pietra, immagine, led

COLORI

chiaro, extrachiaro, fumé, bronzo, blu, verde
molti colori trasparenti o opachi a richiesta

FORMA

le normali forme legate al vetro

FORI

Altamente sconsigliati

GARANZIA

un anno sul riscaldante

IMBALLO

cassa Legno

DEMISTING MIRROR DETAILS
GLASS THICKNESS
GLASS THICKNESS
GLASS THICKNESS
GLASS THICKNESS

mm 3
mm 4
mm 5
mm 6

WEIGHT 7,5 Kg / sq.mt
WEIGHT 10,0 Kg / sq.mt
WEIGHT 12,5 Kg / sq.mt
WEIGHT 15,0 Kg / aq.mt

HEATING AREA MAX

mm 1200 x 2000 mm

TEMPERATURE MAX

15°C

VOLTAGE

12V, 24V, 110V, 240V - 50 Hz, 60Hz

WATTAGE

200 Watt / sq.mt

CONNECTION BOX

mm 30 x 30 x 5

POWER CONNECTION

direct or parallel, 80 cm cable

BASE MIRROR GLASS

clear or low iron float glass

SAFETY

glass lamination or back safety film

DECORATION

fabric mesh, fabrics, stones, pictures, leds

COLORS

clear, low iron, fumé, bronze, blue, green
many transparent or matt colors on request

SHAPE

all the normal shapes available for a float
glass

HOLES

Strongly not recommended

WARRANTY

one year for the heating system

PACKAGING

wooden box

PERCHE’ SRINYOR – GENTLE MIRROR ?
WHY SBRINYOR - GENTLE MIRROR?

SBRINYOR GENTLE MIRROR è al
top della gamma dei vetri antiappannanti con delle
caratteristiche uniche di bellezza
e ricchezza dei particolari.
Viene realizzato con maestria ,
testato e consegnato nel migliore
dei modi.
La personalizzazione assoluta è il
nostro obiettivo primario
assieme alla piena soddisfazione
della creatività.

SBRINYOR GENTLE MIRROR is at
the top of the demisting mirrors
with unique characteristics of
beauty and the wealth of the
features.
It is made with mastery, tested
and delivered the best way.
The absolute customization is
our principal aim together with
the full satisfaction of the
creativity.

PRINCIPALI SETTORI DI UTILIZZO
MAIN SECTORS OF USE

Settore Alberghiero
Settore Residenziale
Settore Nautico e Navale
Centri Sportivi
Centri Benessere e Termali
Edilizia Pubblica e Privata
Architettura d’interni
Arredo bagno

Hotels Sector
Residential Sector
Naval and Yacht Sector
Sport Centers
Wellness and Spa Centers
Private and Private Building
Interiors Architecture
Bath furnishings

HOURGLASS ITALY HGI
di Gallian G. Ruggero
Via Trento 1 - 36045 Lonigo (Vi) –
Italy
Tel. +39 333 266 82 06
info@hourglass-italy-hgi.it
www.hourglass-italy-hgi.it
C.F. GLLGLM58C20E682J P.IVA 03708610245 CCIAA 347277
