www.arklighting.co

DELIVERING LIGHTING SOLUTIONS

Delivering
Lighting Solutions

www.arklighting.co

Ark Lighting
McGann House
Chesham Rd
Barnsley
S o u t h Yo r k s h i r e
S70 2NT

t: 01226 320737
f: 01226 292997
e: sales@arklighting.co
w: arklighting.co

About ARK

Ark Lighting has an innovative range of HID and LED
lighting solutions that cover external and internal areas.
Ark is committed to offering leading edge high efficiency
energy saving lighting solutions which are designed to
meet practical requirements of illumination levels and are
manufactured with trusted engineering principles. With
a vast experience in HID and LED lighting Ark is small
enough to care, yet large enough to cope.
Our customer relationships are key to us, they are as
important to us as our products and as such we pride
ourselves in high levels of customer service, keeping you
informed throughout the process of design, manufacture
and delivery. We pride ourselves on our customer
service which holds true to our family values, with two
generations involved in our business it is hard not to!
We hope that this wealth of engineering and business
experience of over 50 years is reflected in the quality of
our products and in your experience.
We use the latest in manufacturing and design processes
together with innovative ideas to ensure that every
product that we supply is finished to the highest standard
of quality and complies with all relevant EU standards.

Experts Point
LED allow us to create unique, low energy lighting solutions, not to mention their lower
maintenance costs and as investment continues and volumes increase, the price of LEDs should
come down by 10% or more a year.
For some time now LED lighting systems have been used to light up buildings, bridges and
monuments. Due to their flexibility and the possibility to set any desired colour, LEDs offer lighting
solutions, which are not possible with any other existing technologies, such as colour wall
washing, sharp light/shadow lines and avoiding light pollution on windows.
Rapidly expanding R & D team of ARK will bring the world more LED lighting solutions.

Welcome to Ark Lighting

Ark Lighting is a leading UK developer of HID and LED
Luminaires working with technical partners from around
the globe to offer the latest available technology. Our focus
is to provide our clients with innovative engineered
products manufactured to last in the modern environment
encompassed in a stylish shell with energy efficiency and
low carbon emissions always a top priority.

Lighting for all applications

Our range features functional lighting and decorative
contemporary and traditional luminaires, Floodlighting,
Industrial lighting, Bollards, lighting columns, feeder pillars
and LED Signage, LED lamps, Architectural LED products
to create your desired effect. Within our site we hope to
inform and inspire in an easy to use format which is a joy
to navigate.

P roduc ts Inde x

W hy W e D o B e tte r
ARK Q ua lity Control

OUR P R ODUC T S
Order Acknowledge

Prepare Material

Good pre-service

I

P01

Long term cooperation
suppliers to ensure quality
and delivery of raw materials

36 m i n s

Save 24 hours

A B O U T AR K

Save 1 hours

L E D B ulb
L E D Spot L ight

Logistics

3 years of sales commitment,
good after-sales service

Production Complete

UPS DHL Fedex TNT EMS
is our good partner

4 hours

Orders complete in time with high
quality by strictly and
professionally testing

Save 12 hours

Af

n

ls

e

t

R&D

ia
er
at
m
w
Ra

Sa le Support
W a rra nty Polic y

ag

n
me

Raw materials cost
While ensuring the quality of raw materials,
ARK already has more than 600 optional
suppliers. Improve cost control

Management and
R&D cost

ARK uses ERP system which will
significantly enhance its management
efficiency while reduce management cost.

Why We Do Better

Products Index

P51

ARK R&D team consists of 26
researchers which provide ARK
with excellent designs. R&D team
will ensure our 3-year-service and
reduce the maintenance cost at the
same time.

les

tio

n
Ma

L E D C a bine t L ight
L E D R a gid Strip
L E D Wall Was her
L E D P ool L ight

After testing,
ERP arrange storage.

ARK C os t Control

ter
-sa

L o g is t ic s

L E D D ownlight

35 mins

After-sales cost

uc

P31

Testing

Rigorous testing to ensure
the production performance
parameters

ARK cooperates with several international
express delivery companies. And we qoute
best freight.

With automated production lines,
and the introduction of the ERP
system to enhance product quality,
reduce production costs.

od

F le xible L E D S trip

P45

Save 2 hours

Save 2 hours

Logistics cost

Production cost

Pr

P17

P37

40 mins

After production, ERP
automatically arrange
the location of aging

After preparing material,
ERP will list program of
production

Automatic notification
Express

P11

2 hours

Long time aging, increase
the lifepan and quality

L E D F loure s c e nt Tube
Order Completion

P07

2 hours

Save 12 hours

ERP automatically notify
the Purchasing Department,
to prepare material

Aging

Producing

Automatic Production Equipments
to ensure the quality
and high efficiency

LED Flourescent Tube

T8

Solution LED Flourescent Series

Very Energy Efficient
Up to 70% more energy efficient than T8 &
T12 flourescents
Features
Color in KeLvin: 2700K - 7500K
Size: T8
Length: 1“-8” in length

CHAPTER 1

LED Flourescent Tube

50,000 hours or 5.7 when on 24/7
Up to 16 years in an office enviroment
Universal Input Current
85-268V

Recyclable
No toxic mercury
No fluorescent disposal danger or costs

Simple installation
It only takes 3 to 5 miniutes per fixture

Input
Voltage

Model

Color/
CCT

SHELL
TYPE

Dimension

TP XT8-120C-W

White 4271K

Clear Shell

1200mm

3528 SMD

288

1729lm

AC85 265V

17 65W

TP XT8-120C-WW

Warm White 2932K

Clear Shell

1200mm

3528 SMD

288

1659lm

AC85 265V

17 65W

TP XT8-120W-W

White 4271K

Wave Shell

1200mm

3528 SMD

288

1711lm

AC85 265V

17 65W

TP XT8-120W-WW

Warm White 2932K

Wave Shell

1200mm

3528 SMD

288

1623lm

AC85 265V

17 65W

TP XT8-120F-W

White 4271K

Frosted Shell

1200mm

3528 SMD

288

1418lm

AC85 265V

17 65W

TP XT8-120F-WW

Warm White 2932K

Frosted Shell

1200mm

3528 SMD

288

1346lm

AC85 265V

17 65W

Led Type

Led Qty Luminous
Flux

Rated
Power

LED Flourescent Tube

LED Flourescent Tube

01

Extremely Long Life - 5 Year Guarantee

Safer than Fluorescent
Solid state - no glass
No vacuum or pressurized vessel
Impact and shock resistant
Cool to the touch

02

T8

T8
TP-XT8-S120
Descriptions

Model Number
Color/CCT

1200mm

Dimension

LED Type

LED Q'ty

Luminous
Flux

Input Voltage

Rated
Power

Luminous
Flux

Input Voltage

Rated
Power

900mm

TP-XT8-120

TP-XT8-90
1500mm

600mm
TP-XT8-150

TP-XT8-60

TP-XT8-150

Descriptions
Model Number

Color/CCT

TP-XT8-60
Model Number

SHELL Type

SHELL Type

Dimension

LED Type

LED Q'ty

Descriptions
Color/CCT

SHELL Type

Dimension

LED Type

LED Q'ty

Luminous
Flux

Input Voltage

Rated
Power

Why Choose ARK T8

Color/CCT

SHELL Type

Dimension

LED Type

LED Q'ty

Luminous
Flux

Input Voltage

Before

Rated
Power

After

zone

visual dark zone

luminous
efficacy
There is no visual dark zone on the lighting surface with the light
transmission is 86% and the PC dispersant cover. Besides,
the LED chips are not on the sight
while the tube is still on
120 uniform luminous
excellent performance.
intensity zone

heat
dissipation

Additional effective heat dissipation area 73 4508 43 2649 43 2649
69 76
The additional effective heat dissipation area increases 69% and the
speed of heat dissipation increases 50% at the same time. In this way,
the LED in the lowest consumption and reach the longest life span.

LED Flourescent Tube

LED Flourescent Tube

03

Descriptions

120 uniform luminous
intensity zone
30 dim

section

TP-XT8-90
Model Number

The LED chips are visible and there
is a visual dark zone on the lighting
surface. Only the transparent
lampshade and wave lampshade
can be used.

04

T8

T8

TP XT8-120C-W

1M
2M
3M

612Lux
173Lux
92Lux

TP XT8-120C-WW

TP XT8-120W-W TP XT8-120W-WW

543Lux
152Lux
81Lux

572Lux
171Lux
79Lux

TP XT8-120F-W

541Lux
143Lux
75Lux

TP XT8-120F-WW

421Lux
131Lux
63Lux

418Lux
125Lux
63Lux

RETROFIT INSTALLATION INSTRUCTIONS

Step by Step Instructions

ARK LED T8 Lamps replace Fluorescent T8 T12 lamps of the same length
ARK LED T8 lamps may be installed in fixtures holding T8 Fluorescent lamps by simply
rewiring the fixture to bypass the Ballast Green Ray LED lamps work in fixtures with voltages
ranging from 100 277 V

ARK T8
4100K LED Lamp

Total Power
Watts
49
32
32
16
16
16
27
18
26
17 65

Output
Initial Lumens
1579
1407
1357
1062
1108
1218
1198
1136
1258
1729

Efficacy
lm W
32
44
42
66
69
76
45
64
55
98

CRI
75
76
76
72
66
66
64
63
70

4271

remove linear fluorescent lamp

Remove ballast or leave in place
Insert ARK LED T8 lamps in fixture with the
power input end inserted into the powered
lampholder

BALLAST
LAMPHOLDERS

LAMPHOLDERS

for live demonstration
by pass or remove the ballast

63

Disposing of Fluorescent Lamps
http www epa gov region02 mercury mercurylamps html

the installer must

WARNING
Risk of fire or electric shock Refector kit installation requires knowledge of fuorescent lighting luminaires
electrical systems If not qualifed do not attempt installation Contact a qualifed electrician

replace with ARK LED lamp

do not expose wiring to edges of sheet metal or other sharp objects
POWER INPUT END

The end retroft luminaire has been modifed and can no longer operate the originally intended lamp
Risk of fire or shock

Do not use this retroft kit in luminaires employing shunted bi pin lampholders

Note Shunted lamp holders are found only in fuorescent luminaires with Instant Start ballasts Instant start ballasts can
marked on the ballast This designation may be in the form of a statement
be identifed by the words Instant Start or I S
pertaining to the ballast itself or may be combined with the marking for the lamps with which the ballast is intended to be
used for example F40T12 IS
THE RETROFIT ASSEMBLY IS ACCEPTED AS A COMPONENT AS A FLUORESCENT LUMINAIRE WHERE THE SUITABILITY OF
THE COMBINATION SHALL BE DETERMINED BY CSA OR AUTHORITIES HAVING JURISDICTION
• The retroft kit is suitable to be installed in an IC recessed ceiling mounted luminaire enclosed with a diffuser having a
maximum of 4 LED tube lights
• The retroft kit is not suitable to be used with emergency exit luminaires
• For more information contact the LED luminaire retroft kit manufacturer

reuse the existing fixture

LED Flourescent Tube

LED Flourescent Tube

05

WARNING

WARNING

Fluorescent lamps contain mercury which is released as
poisonous vapors if the lamps are broken Mercury can also be
absorbed through the skin by handling broken fluorescent lamps
For these reasons care must be taken to dispose of fluorescent
lamps safely Here are a couple helpful links
Clean up of broken Fluorescent Lamps
http www epa gov mercury spills index htm

THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED

To prevent wiring damage or abrasion

Strip plastic from ends of wire connected to
lampholders
Using the two wires from only one lampholder
connect one to neutral and one to hot
WARNING This lampholder must be
non shunted

Lamp Replacement Compliance Label

WARNING

Remove ballast cover

Cut all lampholder leads from ballast leaving
them as long as possible

CCT
K
3667
3758
3756
4657
3182
3221
3394
2993
3579

WARNING
Risk of fire or electric shock The electrical rating of these products are 100 277 Vac
determine whether they have 85 268 V at the luminare before installation

Carefully remove existing Fluorescent lamps

Disconnect power line from ballast fixture

ARK T8 4100K LED in comparison
with CALiPER T8 LED test samples
CALiPER
Test ID
08 121
09 13AB
09 13CD
09 17
09 39
09 40
09 46
09 48
avg

Turn off power to fixture

06

L E D B ulb

QB
60mm
114mm
84mm

E27
E27

B22

Gu10

Attention: The base of this product can according to customer’s order

TP-QB LED (CRI>90) BULB
GIVES YOU NEW FEELING OF READING

CHAPTER 2

LED BULB

0.5M

337

1.0M

86

2.0M

21

0.5M

326

1.0M

81

2.0M

20

Bulb Driver

Feature
Replace a incandescent lamp and drop from 35W to 6W

Model

07

Color

LED Type

CCT

Rated Power
Consumption

CRI

Luminous
Flux

Working
Voltage

Beam Angle

LED Bulb

LED Bulb

High-CRI Protect your eyes, reduce your fatigue when reading
Patent design, TP-QB is so far the hightest CRI avialable in the market

Weight

08

QBQ

QBX

unite: mm

56

56
AC

3528

Driver
Incl

100-266V

71.1
lm/w

Edison

AC
100-266V

Driver
Incl

6.5W

B22

Gu10

Descriptions

Model
Number

60mm

5.0W

Gu5.3

Color

LED Type

Light Output
(lumen/m)

Base

Voltage (V )

CCT

CRI

Max Power
Consumptio
n(W/m)

White
Warm White

114mm
84mm

TP-QBX-W

Feature
Cree

AC

Driver
Incl

100-266V

3W

E14

Replace a incandescent lamp and drop from
15W to 3W
Cree made my life more durable
50 000 hours

and up to

Candle lights designed, your life is full of
romance

unite: mm
95 0

E27
E27
TP-QBX-WW
Feature

TP-QBC-W
Model

09

71lm/w, 4050 SMD LED, 20PCS

Color

LED Type

CCT

Rated Power
Consumption

CRI

Luminous
Flux

Working
Voltage

Beam Angle

Weight

Model

Color

LED Type

CCT

Rated Power
Consumption

Cree 3w

3 0W

Cree 3w

3 0W

CRI

Luminous
Flux

LED Bulb

LED Bulb

Replace a incandescent lamp and drop from 45W to 6.5W

TP-QBC-W
Working
Voltage

Beam Angle

Weight

10

LED Spot Light

PAR30

Solution LED Spot Light Series

CHAPTER 3

TP-PAR30-5W

TP-PAR30-7W

LED Spot Light

Color
White

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

Voltage(V)

LED Spot Light

LED Spot Light

Descriptions
Model Number

Warm White
White
Warm White

11

12

PAR30

Spot Light

TP-PAR30-9W

TP-PAR30-12W

Feature
12 volt MR16 lamps with GU5.3 bi-pin standard base

25
LENS A
90

LENS B

110 volt MR 16 lamps with GU10 turn and lock base
Ideal for replacing Halogen MR16 and GU10′s in track and open fixtures in retail and office environments.

Application
All kinds of exhibitoin halls,store lighting,car showroon,brand authorized
store,department store,supermarket,museum,hall of office building and
all places requiring exhibition lighting

45

65

Feature
Replace a PAR30 and drop from 75W to 8W
Energy Busters – Replace flood or spot lights and save up to 90% of your energy
Available in 5W PAR 16, 6W PAR 20, 8W PAR 30 and 15W PAR 38

Descriptions

Light Color

Correlated Color Temperature CCT

in Kelvin K

Model Number

Color

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

Voltage (V)

White
Warm White

Warm White

Warm White
2700K

3000K

Pure White
4000K

White

Cool White

6500K

Warm White

9000K

White

Model Number

Color
White
Warm White
White

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

Voltage(V)

White
Warm White
White
Warm White

LED Spot Light

LED Spot Light

Warm White

Descriptions

White
Warm White

Warm White

13

14

Spot Light

Spot Light

25
LENS A
90

LENS B

45

55

25
LENS A
90

LENS B

Descriptions
Model Number

Color

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

white

warm white

Voltage (V)

Descriptions

White

Model Number

Warm White

Color

White

warm white

Warm White

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

Voltage (V)

White

White
Warm White

Warm White

White

White

Warm White
White

Warm White

Warm White
White

38

Warm White

white

Features
Low power consumption,
Environment protection, low voltage,
Safe and easy for installation.
Long life span.
Dimensions: 34.5*38 mm
Average life time: 50, 000 hours
Material: Glass, PC, high quality alloy material for radiation function

Descriptions
Model Number
Color

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

Voltage (V)

White
Warm White

Application
All kinds of exhibitoin halls,store lighting,car showroon,brand authorized
store,department store,supermarket,museum,hall of office building and
all places requiring exhibition lighting

White
Warm White
White

White
Warm White

Descriptions
Model Number

Color

White
Warm White
White

LED Type

Light Output
(Lux from a
meter)

CRI

Light Output
(lumen)

Beam Angle
(dagrees)

Voltage (V)

LED Spot Light

LED Spot Light

Warm White

White

Warm White

Warm White

15

16

L E D F le xible S trip

SBS

SBS series make me surprised.
Five meters SBS flexible strip with
5212LM (max) brightness which
makes my ideas come into reality.(
New World Hotel Beijing)
Nancy
Lighting Designer

CHAPTER 4

Connectors for cut

Flexible LED Strip
172

142

103

86
500mm 20 Luminance warm white 3200K

Model Number

Color

TP SBS W

White

Length LED
Light Output Light Output Beam Angle Voltage Current Max Power Continuous
LED Type
Consumption Connection
m Q ty
degrees
V C
Amps
mcd
lumen
W
m
5

600

5

600

Power 3500 X 600
SMD
Top LED 3000 X 600

5212

120

12

7.5

90

5

3967

120

12

7.5

90

5

LED Flexible Strip

LED Flexible Strip

307

500mm 20 Luminance white 6500K

TP SBS WW Warm White

17

338

18

BS

BS

Assembly

Information

Application

The base of the strip is distributed with several strips which with lots of
two-side adhesive on the back surface. A clean and dry installation place
is required. Make sure the surface of installation place is smooth.
Remove the adhesive backing completely. When the strip is assembled
2
appropriately, press the strip with 20N/cm

The minimum of bending radius is 2cm. The strip can be bent to a
smaller radius of circuit board without electronic components which can
avoid damage.

Great advantages

Soldering can only be operated on the corresponding soldering pads
(marked “+/-). Make sure the soldering time does not surpass 10
seconds and the temperature does not exceed 260 degrees during
soldering.

Linking operation

A unit is consisting of 3 leds and each unit can be cut (cut in the position
remarked with a scissor).

Connectors
Packing information

Safety Information
The strip and its components can not be mechanically pressed.
Correct electrical polarity needs to be observed.
Ensure the power is adapt to operate the total load.

Parallel connection is highly required as safe electrical operation mode.
Pay attention to ESD precautions during assembling.
Assembly of LED modules includes power supplier must be appropriately.
When installing on metallic or other surface, an electrical isolation point between strip and the installing surface is recomm ended.
Only qualified person allowed to operate installations.

LED Flexible Strip

LED Flexible Strip

Installation must not damage the conducting paths on the circuit board.

Damaged by corrosion will not be materials defect claim. It is the user's responsibility to provide a suitable protection again st moisture,
condensation and other harmful elements.

19

20

HB S

XBS

Dimension drawing

Unit mm

Packing information

Application

Dimension drawing

The applications

of XBS

XBS contains 2 lines of high brightness SMD LEDs on a 16mm wide FPC board like other TOPO flexible strips. The XBS is 5m a reel and it stands out for
its remarkable light output. Each meter of XBS is CCT 6000K which gives more than 1000 lumens while the whole strip gets no heat at the same time.
White color CCT3000K, 4000-4500K and 6000K and other colors are also offered to customers. It will be considered as a excellent light source for
signage, contour and canopy for decorative purpose without hesitation.
XBS can be easily used by end users who are not professors. Costumers can cut the strip along the marks on PCB and do the join work again with our
connector. In this way no length of XBS will be wasted. Costumers can install XBS around any corners with our L and T shape connector.

Unit mm

General Information
The base of the strip is distributed with several strips which with lots of two-side adhesive on the back surface. A clean and dry installation place is
required. Make sure the surface of installation place is smooth. Remove the adhesive backing completely. When the strip is asse mbled appropriately,
press the strip with 20N/cm2
Soldering can only be operated on the corresponding soldering pads (marked “+/-). Make sure the soldering time does not surpass 10 seconds and
the temperature does not exceed 260 degrees during soldering.
The minimum of bending radius is 2cm. The strip can be bent to a smaller radius of circuit board without electronic components which can avoid damage.
A unit is consisting of 6 leds and each unit can be cut (cut in the position remarked with a scissor).
16mm width of Ribbon. LED distance 8.3mm and cut section length 50mm.
XBS Accessories
Packing material is hot-sealing film bag
3m adhesive tape on ribbon backside.
5m as the standard packing length

Correct electrical polarity needs to be observed.
The strip and its components can not be mechanically pressed.
Installation must not damage the conducting paths on the circuit board.
Ensure the power is adapt to operate the total load.
Assembly of LED ribbon includes power supplier must be appropriately. Only qualified person allowed to operate installations.
Pay attention to ESD precautions during assembling.

LED Flexible Strip

LED Flexible Strip

Safety instruction

Serial connection is not recommended. Unbalanced voltage change will cause overload and damage of the strip.
When installing on metallic or other surface, an electrical isolation point between strip and the installing surface is recomme nded.
Damaged by corrosion will not be materials defect claim. It is the user's responsibility to provide a suitable protection again st moisture,
condensation and other harmful elements.

21

22

WB S

WB S 2

Features

Great advantages

Application

Packing information

Application

Features

Dimension drawing

Unit mm

LED Flexible Strip

LED Flexible Strip

23

24

XB S

W DF

XBS silicon sleeve typ e
XBS contains 2 lines of high brightness SMD LEDs on a 16mm wide
FPC board like other ARK flexible strips. The XBS is 5m a reel and it
stands out for its remarkable light output. Each meter of XBS is CCT
6000K which gives more than 1000 lumens while the whole strip gets
no heat at the same time. White color CCT3000K, 4000-4500K and
6000K and other colors are also offered to customers. It will be
considered as a excellent light source for signage, contour and
canopy for decorative purpose without hesitation.
XBS can be easily used by end users who are not professors.
Costumers can cut the strip along the marks on PCB and do the join
work again with our connector. In this way no length of XBS will be
wasted. Costumers can install XBS around any corners with our L and
T shape connector.

Applications

Dimension drawing

Dimension drawing

Accessories

Unit mm

Features

Unit mm

Link options

Application

LED Flexible Strip

LED Flexible Strip

25

26

W DB S
W MB S

Application

Features

LED Flexible Strip

LED Flexible Strip

27

28

CS

F le xible S trip C onne c tion
Flex Strip Connector Operation Instruction

TP-BS-C1

TP-SBS-CON3

TP-BS-C2

Step A 1 : Pull out the black clip carefully.
Step A 2 : Cut the flexible led strip light at the mark “scissors” or by every 3 LED’s.
Step A 3 : Put the flexible led strip light in the space between the clip and connector .
Step A 4 : Push the clip in original position.

TP-XBS-CON3

Application

TP-BS-C3

Step B 1 : Pull out the black clip of each side carefully.
Step B 2 : Pull the flexible led strip light in the space between the clip and connector at one side .
Step B 3 : Put the flexible led strip light in the space between the clip and connector at the other
side ,and push the clip in original position.

Great advantages

Dimension

Circuit drawings

TP-BS-C4

TP-BS-C5
TP-CS

W

Package

TP-SBS-CON4

TP-SBS-CON4

TP-XBS-CON5

TP-BS-C6

Signle color Strip connect to DC portable
power supplier

RGB Strip connector attention
TP-CS-W2

single color

TP-BS-C4

Safety Information
The strip and its components can not be mechanically pressed.
Installation must not damage the conducting paths on the circuit board.
Assembly of LED ribbon includes power supplier must be appropriately.
Only qualified person allowed to operate installations.
Correct electrical polarity needs to be observed.

Accessories

TP-BS-C6
For SMD5050 single color,
2 wire out: + and For SMD5050 RGB strip
4 wire out: + , R, G and B

RGB color

Parallel connection is highly required as safe electrical operation mode.
Serial connection is not recommended.
Unbalanced voltage change will
cause overload and damage of the strip.

When installing on metallic or other surface,
an electrical isolation point between strip
and the installing surface is recommended.
Pay attention to ESD precautions during
assembling.
Damaged by corrosion will not be materials
defect claim. It is the user's responsibility
to provide a suitable protection against
moisture, condensation and other harmful
elements.

LED Flexible Strip

LED Flexible Strip

29

Ensure the power is adapt to operate the
total load.

30

L E D D ownlight

S D L 01

Solution LED Downlight Series

SDL01

SDL01 unite: mm

60

SDL01-A

CHAPTER 5

SDL01-B

40

35

LED Downlight

LED Downlight

LED Downlight

31

32

L E D D ownlight
SDL02

S D L 01
BDL03

unite: mm

SDL03

BDL06

unite: mm

LED Downlight

LED Downlight

33

34

B DL

BDL09

C DL
CDL01

unite: mm

CDL02

50

LED Downlight

LED Downlight

unite: mm

22.00

35

36

L E D R igid S trip

HR S
Epistar

3528 LED

HRS is so far the brightest rigid strip available in the market.

TP-WHRS

TP-HRS

0.5M

417

1.0M

204

2.0M

121

TP HRS-0560W

Solution LED Ragid Strip Series

578mm

1.0M

174

2.0M

102

LED Ragid Strip. Cabinet Light
Model Number

TP WHRS-0560W

Color
Whi te

TP-WHRS-5060WW

War m White

TP- WHRS-5060W2

Whi te

TP- WHRS-5060WW2
TP-HRS-5060W

LED Type

High Flux
Top SMD
LED 5060

War m White
Whi te

TP-HRS-5060WW

War m White

TP- HRS-5060W2

Whi te
War m White

High Flux
Top SMD
LED 5060

Length (m)

LED Q'ty / Light Output Light Output Beam Angle Voltage (V
PC
(mcd)
(Lumen)
(degrees)
DC)

Current
(Amps)

Max.Power
Consumptio
n

0.5

30

30x12000

885

120

12

0.6

12

0.5

30

30x10200

762.2

120

12

0.6

12

1

60

60x12000

1740

120

12

1.2

24

1

60

60x10200

1473.5

120

12

1.2

24

0.5

30

30x12000

1021

120

12

0.6

12

0.5

30

30x10200

846

120

12

0.6

12

1

60

60x12000

1948

120

12

1.2

24

1

60

60x10200

1671

120

12

1.2

24

LED Rigid Strip

LED Rigid Strip

TP-WHRS-5060W

TP- HRS-5060WW2

37

354

1.6mm

CHAPTER 6

29-18.7mm

0.5M

38

L E D R igid S trip

RS

Why we can make the most bright rigid strip

Application:
Architectural decorative lighting.
Path & Contour Marking.
Amusement park, theater & aircraft cabin mood lighting.
Emergency hallway lighting.
Auditorium walkway lighting.
Stairway accent lighting.
Concealed lighting,
Backlighting for signage letters.
Channel letter lighting.
Cove lighting.

Heat problem is the development bottleneck of highlights LED lamp , the following data illustrates
how we help WHRS to solve the problem.

Chip life test:
Affect of Tj on Luminous Maintenance
If 150mA
Dot line Expected Life

Features:
Can be cut every 3 LEDs along the mark on PCB.
Solid-state, high shock / vibration resistant.
Low power consumption; no heat.
Compact size to suit narrow space installation.
Easily can be connected by cable connector.
Maintenance free, easy installation.

100

80
29-18.7mm

60

480mm

578mm

8mm 29-16mm

40

0

10

100

1000

10000

100000 h

5060 Series Rigid Strip

X-Connector

S-Connector

Curves of beam angle and relative brightness

Model Number
TP- RS- 3528W

Color

LED Type Length (mm)

White

TP- RS- 3528WW Warm White
Top SMD
LED
3528(1210)

LED Q'ty / Light Output Light Output Beam Angle Voltage (V
DC)
PC
(mcd)
(Lumen)
(degrees)

Current
(Amps)

Max.Power
Consumptio
n

480

30

30x1200

120

120

12

0.2

2.4

480

30

30x850

100

120

12

0.2

2.4

480

30

30x600

92

120

12

0.2

2.4

480

30

30x600

108

120

12

0.2

2.4

Red

TP -RS-3528Y

Yell ow

TP -RS-3528B

Blue

480

30

30x250

63

120

12

0.2

2.4

TP-RS- 3528G

Gr een

480

30

30x650

117

120

12

0.2

2.4

TP- RS- 5060W

White

578

30

30x3500

403

120

12

0.6

7.2

578

30

30x3000

313

120

12

0.6

7.2

578

30

30x1500

302

120

12

0.6

7.2

578

30

30x1800

300

120

12

0.6

7.2

TP- RS- 5060WW Warm White
TP- RS- 5060R

Red
Top SMD
LED 5060

TP -RS-5060Y

Yell ow

TP -RS-5060B

Blue

578

30

30x750

336

120

12

0.6

7.2

TP-RS- 5060G

Gr een

578

30

30x1200

403

120

12

0.6

7.2

578

30

30x1500

133

120

12

0-0.6

0-7.2

LED Rigid Strip

LED Rigid Strip

TP- RS- 3528R

TP-RS-5060RG B RGB

39

3528 Series Rigid Strip

Two Type connector

Patent designed:
Button of 5060 LED chip with high
scale heat sink This design can help
the high flux 5060 normal running
heat sink

1.6mm

20

1.6mm

Relative Luminous Intensity

120

40

WR S

WR S

Installation diagram

Model Number

TP-WRS-5060W
TP-WRS-5060W

TP-WRS-5060WW

TP-WRS-5060WW

TP-WRS- 3528W
TP-WRS-3528WW

Length (m)

LED Q'ty / Light Output Light Output Beam Angle Voltage (V
PC
(mcd)
(Lumen)
(degrees)
DC)

Current
(Amps)

Max.Power
Consumptio
n

Whi te

0.5

30

30x1200

114

120

12

0.2

2.4

War m White

0.5

30

30x850

95

120

12

0.2

2.4

Red

0.5

30

30x600

87.4

120

12

0.2

2.4

TP- WRS- 3528Y

Yel low

0.5

30

30x600

102.6

120

12

0.2

2.4

TP- WRS- 3528B

Blue

0.5

30

30x250

59.8

120

12

0.2

2.4

TP-WRS-3528G

Green

0.5

30

30x650

111.1

120

12

0.2

2.4

TP-WRS- 3528W2

Whi te

1

60

60x1200

228

120

12

0.4

4.8

Top SMD
LED
3528(1210)

War m White

1

60

60x850

190

120

12

0.4

4.8

TP- WRS- 3528R2

Red

1

60

60x600

174.8

120

12

0.4

4.8

TP- WRS-3528Y2

Yel low

1

60

60x600

205.2

120

12

0.4

4.8

Blue

1

60

60x250

119.7

120

12

0.4

4.8

Green

1

60

60x650

222.3

120

12

0.4

4.8

TP-WRS-5 060W

White

0.5

30

30x3500

382.8

120

12

0.6

7.2

Warm White

0.5

30

30x3000

297.3

120

12

0.6

7.2

TP-WRS-5 060R

Red

0.5

30

30x1500

286.9

120

12

0.6

7.2

TP-WRS-5 060Y

Yellow

0.5

30

30x1800

285

120

12

0.6

7.2

TP-WRS-5 060B

Bl ue

0.5

30

30x750

319.2

120

12

0.6

7.2

TP-WRS-5 060G

Green

0.5

30

30x1200

382.8

120

12

0.6

7.2

1

30

3 0 x1 5 0 0

1 2 6 .3

120

12

0 -0 .6

0-7 .2

1

60

60x3500

756.3

120

12

1.2

14.4

LED Rigid Strip

TP-WR S-5 0 6 0 R GB

R GB

TP-WRS-5 060W2

White

Top SMD
LED 5060

Warm White

1

60

60x3000

588.6

120

12

1.2

14.4

TP-WR S-5 060 R2

Red

1

60

60x1500

566.2

120

12

1.2

14.4

TP-WRS-5 060 Y2

Yello w

1

60

60x1800

564.3

120

12

1.2

14.4

TP-WR S-5 060B2

Bl u e

1

60

60 x75 0

631.6

120

12

1.2

14.4

TP-WRS-5 060WW2

TP-WRS-5 060 G2
TP-WRS-5 0 6 0 R GB2

Gre en

1

60

60x1200

756.3

120

12

1.2

14.4

R GB

1

60

6 0 x1 5 0 0

24 9.4

120

12

0 -1 .2

0-1 4 .4

LED Rigid Strip

TP- WRS-3528B2
TP-WRS-3528G2

TP-WRS-5 060WW

41

LED Type

TP-WRS- 3528R

TP-WRS- 3528WW2

unite: mm

Color

42

Using quality aluminum heatsink for excellent
heat dissipation.
Innovative lighting with ultra slim and
lightweight profile. No UV/IR,low heat and
long lifetime.

L E D C a bine t L ight

50mm

TP-CID-SL03
10mm

Extremely thin LED light gives out high and even light with low heat. It is ideal
for furniture decorative lighting, display and show case.

10mm

TP-CID-DLIR
LED
9PCS
Wattage 2.8W

8.8mm

9PCS
1.8W

50mm

165mm

LIGHT
COLOUR

TP-CID-DL02
9PCS
1.8W

60mm

60mm

WATTAGE MATERIAL

LED QUANTITY Light Output
LED WIGHT DIMENSION
LED
lumen

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

1.8W

Glass,Alu
minum

9pcs

138.00

85g

Dia 60mm*7 m
m

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

1.8W

Acrylic
,Aluminum

9pcs

132.00

85g

6 0*6 0*7mm

1.8W

Acrylic
,Aluminum

9pcs

141.00

1 65mm*5 0m
m*8 .8mm

2.8W
(with IRSensor)

Acrylic
,Aluminum

9pcs

141.00

1 65mm*5 0m
m*8 .8mm

18PCS

256.00

125g

300*18 *7mm

30PCS

429.00

190g

500*18 *7mm

12W

60PCS

839.00

380g

10 00*18*7mm

3.6W

18pcs

251.00

3 48mm*1 4m
m*18mm

24pcs

343.00

4 48mm*1 4m
m*18mm

30pcs

413.00

5 48mm*1 4m
m*18mm

57pcs

823.00

1000 mm*14m
m*18mm

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

17mm

LED
9PCS
Wattage 2.8W


Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

325mm

IR Sensor Switch

Model
Number

3.6W
6W

4.8W
6W

PC,Alumin
um

Acrylic
,Aluminum

12W

3.6W

PVC

18pcs

257.00

100g

3 25mm*1 0m
m

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

2.4W

Acrylic
,Aluminum

12pcs

65.00

120g

2 95mm*2 3m
m*7mm

6.4W

27pcs

359.00

4 55mm*5 0m
m*8 .8mm

8.2W

36pcs

486.00

6 55mm*5 0m
m*8 .8mm

45pcs

643.00

7 55mm*5 0m
m*8 .8mm

45pcs

621.00

8 55mm*5 0m
m*8 .8mm

11.8W

54pcs

734.00

9 55mm*5 0m
m*8 .8mm

13.6W

63pcs

850.00

1155 mm*50m
m*8 .8mm

3.6W

18pcs

240.00

5 80mm*3 5m
m*120 mm

30pcs

408.00

8 80mm*3 5m
m*120 mm

TP-CID-SILR02
Length
LED
Wattage

IR Sensor Switch

500mm
30PCS
6W

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

500mm
The unique triangular design. Innovative
lighting with ultra slim and lightweight profile.
No UV/IR, low heat and long lifetime.

580mm/380mm
120mm

35mm

TP-CID-WLPIR
Length
580mm
LED
18PCS
Wattage 3.6W

880mm
30PCS
6W

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

10W
10W

Acrylic
,Aluminum

Acrylic
,Aluminum
6W

LED Cabinet Light

Warm(3 200k/
420 0k)
cool(56 00k/6 0
00 k)
wh ite , blue,
yel low, red,
g reen

ARK Keep Your Cabinet Out Of Dull

8.8mm

move

TP-CID-SLIRO1
27PCS 27PCS
LED
Wattage 5.4W 6.4W

IR Sensor Switch LED Lighting For Cabinet FurnitureDisplay

500mm

IR Sensor Switch

44

L E D W a ll W a s he r

WS LS

48
.5
m
m

Linear LED Wall Washer Demos
To give an idea how the effect of the linear wall washer will be we have placed some
pictures below that we have taken during testing the linear LED wall washer:

2
50

0
8.0

mm
1

6
04

mm

mm

The linear high power LED wall washers are high power LED lights
that are used for decorative lighting and highlight, or wash walls, of
buildings, clubs, hotels, stages, parks, plazas, commercial building
facades, art galleries, etc., with different kind of colors.
The linear LED wall washer can even change their colors while
projecting. The RGB linear LED wall washers can project 16.7 million
colors and change the color by programming the LED wall washer the
way you want to.

Feature

CHAPTER 7

LED Wall Washer. Pool Light

Material: Waterproof aluminum alloy, 3mm euphoric toughened glass;
Color: Single color and RGB full color;
Voltage: DC24V;
Constant Current: R/G/B 320mA, max current: 2A;
Projection distance: 12-45 meters;
Viewing Angle: 8-120 degrees;
IP Rank: Ip65;
Control Method: DMX512 controller optional;
Life Span: > 100,000 hours

Application
Lighting for Clubs;

Commercial Building Bacades

Lighting for Parks;

Lighting;

Lighting for Plazas;

Art Gallery Lighting,

Model Number

Color

Light Source

Power Luminous Voltage

Protection

Size (LxWxH)

L E D W a ll W a s he r

L E D W a ll W a s he r

45

Lighting for Stages;

Lighting for Stages;

46

WS L

W S B -W S R
One-Row High Power LED Wall Washer Lights
The one-row high power LED wall washers are high power LED lights that
are used for decorative lighting and highlight, or wash walls, of buildings,
clubs, hotels, stages, parks, plazas, commercial building facades, art
galleries, etc., with different kind of colors.
The one-row LED wall washer can even change their colors while
projecting. The RGB one-row LED wall washers can project 16.7 million
colors and change the color by programming the LED wall washer the way
you want to.

Features

Installing Instruction

Model Number

Color

Available in black and white for the light body;
Lighting source: 1 Watt high power LED;
Color Range: Different brightness of red, green and blue LED combined to
produce 16777216 colors (flash changing, fade changing, chasing changing)
or 10 functions(including seven static single color) for your choice freely;
Material: Waterproof aluminum alloy, 3mm euphoric toughened glass;
Operating Voltage: AC 90-264V/AC 170-250V;
Beam Angle: 10-120 degrees;
Projection distance: 12-90 meters;
Control way: Control inner DMX 512;
Controlling System: DMX controller, DMX console and Connecting control
mode;
Connector: 3-pin waterproof signal connector;
Connecting mode: Standard signal cord and power cord;
IP Rank: Ip65;
Life Span: > 100,000 hours.

Light Source Power Luminous Voltage

Project
Distance(m)

Feature

456

mm

Lighting source: 36pcs 1 Watt high power LED;
Material: Waterproof aluminum alloy, alnico shell, 3mm euphoric toughened glass;
Source: 1W high power LED;
Color: Single color and RGB full color;
Working Voltage: 100-240V AC;
Max Current: 220V, 0.21A;
mm
Constant Current: R/G/B 320mA;
254
Projection distance: 12-55 meters;
Viewing Angle: 8-120 degree;
Control way: Control inner, DMX 512 control;
IP Rank: Ip65;
Life Span: > 100,000 hours.

Application
Landscape Lighting;
Stage Lighting;
Architectural decorative lighting;
Green landscape lighting.

Project Distance(m)

Size (LxWxH)

Feature
TP-WSRS-RGB

Power Consumption

36 Watt

LED Chip

3W Three in one RGB

Lumen
Beam Angle

0-600lm
25

Number of LEDs

12 LEDs

Current

LEDs 350mA

Protection Rating

IP67

Cover Material

Fiber

Housing

Aluminum

Operating Temperature

47

40 C

L E D W a ll W a s he r

L E D W a ll W a s he r

Model Name

Round Color-Changing LED Wall Wash. It’s a multi-color LED spotlight that’s so light
nearly anyone can lift and move it. Fabulous color-changing lights can come in small
packages. Need proof? Each Round RGB Wall Washer weighs just over 6 pounds and is
less than 8 inches tall. This LED wall light will make any party or event a colorful and
dynamic affair. Use it to decorate indoor and outdoor settings. It’s a brilliant, theatrical tool
for lighting clubs, theaters, stages, and auditoriums, and for highlighting buildings,
gardens, restaurants and more. Forget bulky spotlight contraptions. Whether it’s an
innovative, spectacular architectural accent lighting you crave or a simple, subtle approach
to background wall color, this full color spotlight is spectacular.

80 C

48

L E D P ool L ight

L E D P ool L ight

Feature
Module No.: Led Underwater/Fountain light IL-7F01-RGB;
Protection degree: IP68;
Materials: Stainless steel S304 trim, stainless housing;
Led qty / Power comsumption: 1.5W*7 pcs RGB 3in1 / 10.5W ;
Led qty / Power comsumption: 3W*7 pcs RGB 3in1 / 18.7W ;
View angle: 25 / 45 degrees;
Light colors available: RGB(3 chips in 1 led) ;
Working Voltage: 12V & 24V DC;
Brass cable gland; 5mm / 10mm tempered glass;
Power and driver;
Silicone gasket;
Average lifetime: 40,000-50,000 hrs.

Power

Swimming pool light;
Fountain light;
Fish ponds;
Artificial waterfalls and rockeries;
Lawn.

L E D P ool L ight

L E D P ool L ight

49

Application

50

OE M

W a rra nty P olic y

Warranty Policy
1. All products are, at the time of shipment, warranted to be free from defects
in material and workmanship under normal service and use, provided that
installation or renewal is in accordance with manufacturer's instructions.
2. The warranty lasts 3years, counting from the date of shipment from ARK.
3. If any product(s) appears not to meet the warranty specified above, and
then after ARK has examined and tested the allegedly non-complying
product(s) and found said product(s) to be in fact defective within the above
warranty, ARK will at its option either furnish a replacement for or issue a
credit for the purchase price of product(s) thereof which proves to be not in
compliance with the aforesaid warranty.
4. The fitting of a replacement supplied free of charge under warranty does not
extend the original warranty period cover.
5. ARK does not automatically accept liability for associated or
consequential loss of any kind whatsoever, but due consideration will be given
in cases where product(s) is confirmed as defective after examination and
test.
6. This warranty does not apply to any failures which prove to be the result of
misuse, negligence, accident, maladjustment or repair.

Sales Support

Sales Support

ARK

ARK

51

52

W a rra nty P olic y

Warranty Policy Data
P r o d uc t

3 y e a rs

5 y e a rs

LED Cabinet Light
Light Light
LED Panel
Underwater

LED Flexible Light
LED Ragid Light Bar
LED Flourescent Tube
LED Downlight
LED Wall Washer
LED Bulb
Led Control
Pool Light

What excluded from coverage is as following:
(a) Damage that result from abuse and misuse such as improper
operation, storage, accident or neglect;
(b) The defects during shipping;
(c) Defects or damages resulting from the use of Non-TOPO branded
or certified products, accessories or other equipment;
(d) Other acts which are not the fault of TOPO. This warranty is the
only one TOPO warranty, no other exists.

Warranty Policy

Warranty Policy

53

54


Related documents


ark led catalogue 2011
spracingf3 manual latest
nature led linear light catalog 2017
lumishore 2014 catalog lumishore ltd
sedna lighting c37 cal37 lamps spec sheet
sedna elite led street light spec sheet

Link to this page


Permanent link

Use the permanent link to the download page to share your document on Facebook, Twitter, LinkedIn, or directly with a contact by e-Mail, Messenger, Whatsapp, Line..

Short link

Use the short link to share your document on Twitter or by text message (SMS)

HTML Code

Copy the following HTML code to share your document on a Website or Blog

QR Code

QR Code link to PDF file ARK LED CATALOGUE 2011.pdf
