BlueOptics BO56HXX640DT1 2 4 8GBASE CWDM SFP+ Transceiver

BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver SFP+ CWDM 8.5G 1270 – 1330nm Single mode Optical Transceiver Features Description The BlueOptics© BO56HXX640DT1 SFP+ transceiver is a high performance, cost effective module supporting a datarate up to 8.5Gbps with 40 Kilometer link length on single mode fiber. BlueOptics© transceivers are 100% compliant with SFP+ Multi-Source Agreement (MSA). All BlueOptics© SFP+ transceivers are always equipped with digital diagnostic function compliant to MSA SFF-8472. Using digital diagnostic, BlueOptics© transceivers provide the following real information: - SFP+ time Supply voltage Laser bias current Laser average output power Laser received input power Temperature The transceiver consists of five sections: A DFB transmitter, a PIN photodiode, a trans-impedance preamplifier (TIA), the LD Driver and the digital diagnostic function. Applications  Multi-rate 8x / 4x / 2x Fiber Channel  Compliance with Fiber Channel FC-PI-4 800SM-LC-L -1-  8.5Gb/s serial optical interface  DFB laser transmitter 1270nm – 1330nm  PIN photo-detector  Hot-pluggable SFP+ footprint compliant to SFF-8431  Duplex LC/UPC interface  2-wire interface for management  Metal enclosure, for lower EMI  RoHS compliant and lead-free  Single +3.3V power supply  Compliant with SFF-8472  Case operating temperature - type pluggable Commercial: 0°C to +70°C Extended: -10°C to +80°C Industrial: -40°C to +85°C optical  BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver Warnings Order Information Handling Precautions: This device is susceptible to damage as a result of electrostatic discharge (ESD). A static free environment is highly recommended. Laser Safety: Even small radiation emitted by laser devices can be dangerous to human eyes and lead to permanent eye injuries. Be sure to avoid eye contact with direct or indirect radiation. Part No. BO56HXX640DT1 DDM 0°C to +70°C BO56HXX640DT1EX -10°C to +80°C BO56HXX640DT1IN -40°C to +80°C XX can be following Wavelength: Warranty Every BlueOptics© transceiver comes with a 5 year replacement warranty and lifetime support. For a warranty inquiry, please contact your CBO sales representative. This warranty only covers the first user of the equipment. Temp. Wavelength xx Wavelength xx 1270nm 27 1310nm 31 1290nm 29 1330nm 33 Standard Co. Regulatory Compliance Important Notice Performance figures, data and any illustrative material provided in this data sheet are typical and must be specifically confirmed in writing by CBO before they become applicable to any particular order or contract. In accordance with the CBO policy of continuous improvement specifications may change without notice. The publication of information in this data sheet does not imply freedom from patent or other protective rights of CBO or others. Further details are available from any CBO sales representative. Installation Before installation attach an ESD-preventive wrist to ensure not to damage the transceiver or hardware. BlueOptics© BO56HXX640DT1 can be installed in any Small Form Factor Pluggable+ (SFP+) port. You can install the BO56HXX640DT1 regardless if the system is powered on or off, because it is hot-swappable. Insert the transceiver into the SFP+ port and remove the dust cap. You can now connect your cable. -2- Feature Electrostatic - IEC/EN 61000-4- 2 Discharge (ESD) Electromagnetic - FCC Part 15 Class B EN 55022 Interference (EMI) - Class B (CISPR 22A) Laser Eye Safety - FDA 21CFR 1040.10, 1040.11 - IEC/EN 60825-1, 2 Component Recognition - IEC/EN 60950, UL RoHS - 2002/95/EC EMC - EN61000-3 Class 1  BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver 1. Absolute Maximum Ratings Parameter Storage Temperature Storage Ambient Humidity Symbol Ts HA Min. -40 5 Typ. Max. 85 95 Unit ºC % 2. Recommended Operating Conditions Parameter Case Operating Temperature Ambient Humidity Transmission Distance Coupled Fiber Symbol Tcase HA Min. 0 -10 -40 5 Typ. Max. 70 80 85 70 40 Unit ºC Note BO56HXX640DT1 BO56HXX640DT1EX BO56HXX640DT1IN % KM Single mode fiber 9/125µm SMF 3. Electrical Interface Characteristics Parameter Power Supply Voltage Signal Input Voltage Transmitter Input differential impedance Single ended data input swing Transmit Disable Voltage Transmit Enable Voltage Transmit Disable Assert Time Receiver Differential data output swing Data output rise time Data output fall time LOS Fault LOS Normal Power Supply Rejection Symbol Vcc Icc Min. 3.14 Rin Vin,pp VD VEN Typ. 3.3 Max. 3.46 450 100 Vout,pp tr tf VLOS fault VLOS norm PSR Unit V mA Note Ω 1 180 Vcc-1.3 Vee 1200 Vcc Vee+0.8 10 mV V V µs 300 850 38 38 Vcc-1.3 VccHOST mV Ps Ps V Vee Vee+0.8 V 100 mVpp 2 3 4 4 5 5 6 Notes: 1. Internally AC coupled. 2. Or open circuit. 3. Into 100Ω differential termination. 4. 20-80% 5. LOS is an open collector output. Should be pulled up with 4.7KΩ on the host board. 6. All transceiver specifications are compliant with a power supply sinusoidal modulation of 20 Hz to 1.5 MHz up to specified value through the power supply filtering network shown on page 23 of the Small Form factor Pluggable (SFP) Transceiver Multi Source Agreement (MSA), September 14, 2000. -3-  BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver 4. Transmitter Specifications - Optical Parameter Average Output Power Extinction Ratio Center Wavelength Spectral Width (-20dB) SMSR Transmitter and Dispersion Peanlty RIN Output Eye Mask 1. Symbol POUT ER λC σ Min. -1 3.5 λ-6.5 Typ. Max. 4 λ λ+6.5 1 Unit dBm dB nm dB Note 1 30 TDP RIN 3 dB -128 dB/Hz FC-PI-4 rev 7.0 requirements Notes: λ is 1270,1290,1310 or 1330 5. Receiver Specifications - Optical Parameter Symbol Min. Typ. Max. 1270 1610 Input Optical Wavelength λIN PIN Receiver Sensitivity -15 PSAT Input Saturation Power (Overload) 0.5 PA LOS Assert -30 PD LOS De-assert -18 PA-PD LOS Hysteresis 0.5 Notes: -12 31 1. Measured with 8.5Gb/s; BER =<10 @PRBS=2 -1 non-return-to-zero. Unit nm dBM dBm dBm dBm dB Note 1 6. SFP+ to Host Connector Pin Out Pin 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 Symbol VEET TFAULT TDIS SDA SCL MOD-ABS RS0 LOS RS1 VEER VEER RDRD+ VEER VCCR VCCT VEET TD+ TDVEET Name / Description Transmitter Ground (Common with Receiver Ground) Transmitter Fault indication Transmitter Disable 2-wire Serial Interface Data Line 2-wire Serial Interface Clock Line Module Absent. Grounded within the module Rate Select 0 Loss of Signal indication No connection required Receiver Ground (Common with Transmitter Ground) Receiver Ground (Common with Transmitter Ground) Inv. Received Data Out Received Data Out Receiver Ground (Common with Transmitter Ground) Receiver Power Supply Transmitter Power Transmitter Ground (Common with Receiver Ground) Transmit Data In Inv. Transmit Data In Transmitter Ground (Common with Receiver Ground) -4- Note 1 2 3 4 4 4 5 6 1 1 1 1 1 1  BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver Notes: 1. 2. 3. 4. Circuit ground is isolated from chassis ground. Needs to be pulled up with 4.7k – 10kΩ on host board to a voltage from 2.0V to Vcc + 0.3V. Tx_Disable is an input contact with a 4.7 kΩ to 10 kΩ pullup to VccT inside the module. Mod_ABS is connected to VeeT or VeeR in the SFP+ module. The host may pull this contact up to Vcc_Host with a resistor from 4.7 kΩ up to 10 kΩ. 5. RS1 are module inputs and are pulled low to VeeT with > 30 kΩ resistors in the module. 6. This is an open collector output, which should only be pulled with a resistor of 4.7k - 10kΩ. Pull up voltage between 2.0V and 3.6V. Logic 1 indicates loss of signal; logic 0 indicates normal operation. The output will be pulled to less than 0.8V. Pinout of Connector Block on Host Board 7. EEPROM Information The SFP MSA defines a 256-byte memory map in EEPROM describing the transceivers capabilities, standard interfaces, manufacturer, and other information, which is accessible over a 2 wire serial interface at the 8-bit address 1010000X (A0h). Data Address 0 1 2 3-10 11 12 13 14 15 16 17 18 29 30-35 36 37-39 Field Size (Bytes) 1 1 1 8 1 1 1 1 1 1 1 1 Name of Field Contents (Hex) Description Identifier Ext. Identifier Connector Transceiver Encoding BR, Nominal Reserved Length (9μm) km Length (9μm) 100m Length (50μm) 10m Length(62.5μm)10m Length (Copper) XX XX XX XX XX XX XX XX XX XX XX XX XX 00 XX XX XX XX XX 00 XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX 00 XX XX XX Formfactor 1 16 Reserved 1 3 Reserved Vendor OUI Vendor name -5- Transmittter Code Transceiver Speed Max. link length in KM Max. link length in M Max. link length in M Max. link length in M Max. link length in M Vendor name - OEM  BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver 40-55 16 XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX Vendor PN 56-59 60-61 4 2 Vendor rev Wavelength 62 63 1 1 Reserved 64-65 66 67 68-83 2 1 1 16 Options BR, max BR, min 84-91 92 93 94 95 8 1 1 1 1 Vendor date code Diagnostic type Enhanced option SFF-8472 96-255 160 00 XX CC BASE XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX XX 20 20 XX XX XX XX Vendor SN CC_EXT Product Number depending on Part Vendor revision Transceiver Wavelength Checksum of bytes 062 Part serial number Year, Month, Day Diagnostics Diagnostics Diagnostics Checksum of bytes 6494 Vendor Specific 8. Digital Diagnostics / Digital Optical Monitoring The transceiver provides serial ID memory contents and diagnostic information about the present operating conditions by the 2-wire serial interface (SCL, SDA). The diagnostic information with internal calibration or external calibration are all implemented, including received power monitoring, transmitted power monitoring, bias current monitoring, supply voltage monitoring and temperature monitoring. 9. Recommended Interface Circuit -6-  BO56HXX640DT1 SFP+ CWDM 8.5G 1270 – 1330nm 40KM RoHS Compliant Optical Transceiver 10. Mechanical Specifications (Unit: mm) Contact Information CBO GmbH Friedhofstraße 25 45478 Mülheim an der Ruhr Germany Tel.: Fax.: eMail: web: 0049 – 208 – 777 247 - 0 0049 – 208 – 777 247 - 99 info@cbo-it.de www.cbo-it.de -7-
